Material Specifications
SPECIFICATION
| Motor shell | Body is of SS. 340 grade heavy duty pipe |
| from top to bottom prevent rust formation | |
| Stamping | Made From M45 Grade Quality |
| CRNGO materials Low core Losses | |
| Rotor Shaft | Made from SS 431 |
| Copper rod | Made out of 1DOO/o EC Grade CC Road. |
| winding Wire | EC Grade Copper wire having Superior tensile |
| Strength of insulation working temperature | |
| (-J6@C(+J1 EDOC | |
| C.l. Parts | Grade - 200 FG IS 210 |
| Bush | Laded tin Bronze as per IS |
| Motor Rotor | Dynamically balance with throughout |
| grinding size 6 hard chrome. | |
| Thrust Bearing Set | One segment made from SS 304 grade 6 Plate |
| made from hig grade Carbon having high head | |
| resisting capacity. | |
| Sleeve 6 Parts | Made from SS 410 IS |
| Made from SS 410 IS | Using high quality branded |
| Sand guard | Made from SS |
